Evacuation Diagrams (Signs)

Evacuation Diagrams are required in all buildings, structures or workplace that is, or may be, occupied by people.
All Fire-fighting equipment must be marked with their locations in red, as well as the designated exits in the building which shall be marked in green.
Each Evacuation Diagram is valid to a maximum of 5 years. – AS 3745 & OH&S 2011

Fire Hydrant Block Plans

Hydrant block plans shall be located at the Booster, Fire Control Room and Pump Room and must be water & fade resistant.
Each Fire Hydrant, Stop Valve, and any other fire equipment of importance to the Fire Brigade must be clearly marked on a minimum A3 size. – AS 2419.1

Fire Sprinkler Block Plans

Sprinkler block plans must be located at each set of installation control assemblies and must be water-resistant and fade-resistant.
This shall include the layout of the protected areas and the position of the main stop valves clearly indicated. – AS 2118.1

Fire Alarm Block Plans

Fire Alarm Block Plans, commonly known as Zone Block Plans are required to be installed adjacent to the Fire Indicator Panel, Sub-FIP and Mimic Panels.
This plan must show the location of the FIP as well as the area of each Fire Alarm Zone clearly marked. – AS 1670.1
